AutroGuard® multicriteria protectors

AutroGuard® multicriteria protector provides a new generation technology that simplifies installation and commissioning, and increases fire safety. It is more than a detector, it is a PROTECTOR. It detects fire and gives warning - all in the same device.



Extreme sensor dynamics provide reliable detection that has greatly reduced detection time and nuisance alarms, and expanded the use to cover even more application areas. The type of operation is configurable to Heat, Optical or Multisensor, covering several applications.

It has a wide range of fire safety features included in one single device, providing significant reduction of wiring and installation costs - and a cleaner look.
The self-sensing technology ensures that the protector is as reliable as when it left the factory for its entire life cycle.

DYFI3D technology
AutroGuard® utilizes DYFI3D technology; MultiAngle/MultiWavelength detection with advanced algorithms analyze the unique signatures for each type of fire and nuisance source in a 3D space, enabling the protector to accurately distinguish between real fires and nuisance alarm sources.

SelfVerify®
The SelfVerify® system function provides a calibrated and automatic self-test every 24 hours. It tests the signal path to the system panel, alarm devices and output units. In this way, the self-test ensures that the protector is able to initiate an alarm when it should, and at the correct sensitivity level according to EN 54 part 5 and 7 throughout its lifetime.

Additionally, an advanced Pulse Response Signal analysis is run every other second, verifying 100 % of the components in the signal path and 99 % of the components in the protector.

Cover Detection
As an add-on feature, AutroGuard® provides Cover Detection. We use infrared light to detect if the protector is covered by a dust cap or any other object, and a fault message will appear. The feature can be turned off during maintenance.

Integrated sounder
AutroGuard® can be delivered with an integrated EN 54-3 approved sounder (optional). Sound patterns and sound levels are configurable, with a maximum sound output of 93 dBA at 1 m range.

Integrated Visual Alarm Device (VAD)
AutroGuard® can be delivered with an EN 54-23 compliant integrated Visual Alarm Device (VAD) (optional). It is available in white or red color, and is configurable to 4 different intensities. The flash rate is also configurable (1 or 2 sec.)

Multicriteria protector series V-430

Protector series for land and marine applications

SIL2 approved multicriteria protector series V-530

Protector for hazardous and petrochemical, oil and gas installations
